Product number:
5091300
Product information
The bottom heating 1500 W / 230 V is installed by our expert staff.
Bottom heating thermostatically adjustable for tanks, honey creamers and honey extractors with inner-Ø 69 - 77 cm.
Login
accessories
5022600
CFM-Honey creamer 600 kg
In the tank you can stir up to 600 kg of honey. The combination of paddle screw and rake always transports the honey from the bottom to the top during the stirring process. This has the advantage that you can use the creamer even when only 1/3 full (rake has to be covered with honey)!
Technical details:
• Flat gear motor 1100 W / 400 V
• Approx. 18 rpm
• Paddle screw with rake at the bottom
• Minimum filling quantity: 230 kg
• Inner tank Ø 72 cm welded bottom without gap
• Rigid handles
• Tank bottom with slope to the outlet
• Outlet: welded on DN50 dairy thread at bottom level with screwed on DN 50 disc valve
• Material: Stainless steel
• Outer tank height: 125 cm
• Total height: aprox. 150 cm
Weight without/with wrapping: 118 kg / 142 kg
Packed on a pallet
Chargeable weight: 142 kg
Accessories - please order separately:
Item no. 5091300 bottom heating
Item no. 5092100 timer switch
Item no. 5097020 stand for 600 kg creamer
